Item Number: AVZ404
Product Description
*Replacement for KPD674 / KPD675*
Cloud EaZy Networking available to connect this device to Internet automatically in three steps with our free mobile app, EagleEyes. Supports 4 channels of IP / TVI / CVI / Analog HD /960H video input, All channels at 1080P real-time recording, Up to 5MP recording for IP cameras, CMS Lite for 32 devices central management, eSATA interface built-in to connect a disk array for more video storage.
Product Specifcs
| Video System | NTSC / PAL (auto detection) |
| Video Compression Format | H.264 |
| Video Signal | IP / TVI / CVI / Analog HD / 960H |
| Video Input | 4 quadbrid channels |
| Video Input Interface |
Analog Mode Composite video signal 1 Vp-p 75Ω BNC |
| Video Output |
BNC YES (Main Monitor / Call Monitor selectable) |
| Video Resolution | 1080P / 720P / QHD / 960H / Frame / Field / CIF |
|
Max. Recording Rate |
Analog Mode 1080P / 720P / QHD / 960H / Frame / Field / CIF |
|
Max. Recording Rate |
Up to 120 IPS @ 1920 x 1080 |
| Recording Mode | Manual / Timer / Motion / Alarm / Remote |
| Pre-alarm Recording | YES |
| Playback Channel | 4CH |
| Quick Search | Time / Motion search mode |
| Backup Device | USB 2.0 drive / Network |
| Regular Backup | YES |
| Audio Input | 1 audio input |
| Audio Output | 1 audio output (Mono) |
| Hard Disk Storage | 6TB SATA HDD x 2 |
| SATA Interface | YES |
| eSATA Interface | YES (for external disk array connection) |
| Image Quality Setting | SUPER BEST / BEST / HIGH / NORMAL |
| USB Mouse Control | YES |
| Motion Detection Area | 16 × 12 grids per channel |
| Motion Detection Sensitivity | 3 adjustable parameters for accurate detection |
| Event Notification | Push Video / Push Status / FTP / E-Mail |
| Picture Zoom | 2X digital zoom |
| PTZ Control | YES |
| Alarm I/O | 4 inputs, 1 output |
| IR Remote Control | YES (IR receiver built-in) |
| Key Lock (Password Protection) | YES |
| User Level |
4 user levels for different access privilege |
| Video Loss Detection | YES |
| RS485 | YES |
| Camera Title | Supports up to 25 letters |
| Video Adjustable | Hue / Saturation / Contrast / Brightness |
| Date Display Format | YY/MM/DD, DD/MM/YY & MM/DD/YY |
| Daylight Saving | YES |
| Power Source (±10%) | DC12V / 3A |
| Operating Temperature | 10ºC ~ 40ºC (50ºF ~104ºF) |
| Operating Humidity | 10% ~ 85% |
| Dimensions | 345(W)×58.8(H)×223(D) |
| Net Weight (kg) | 2.17 |
