Item Number: AVT2406
Product Description
1/3” CMOS sensor with 1080P video output,Low light sensitivity of 0.1 Lux / F1.6(Wide)~F2.8(Tele), 0 Lux (IR LED ON), Manual adjustment of the brightness of the IR LEDs, Day and night 24-hour surveillance with IR effective distance up to 60 meters, WDR to increase image recognizability in overexposure and dark areas, IP66 for weather-proof application, Camera parameters adjustable when used with AVTECH HD CCTV DVR
Product Specifics
| Pick-up Element | 1/3" CMOS image sensor |
|---|---|
| Number of Pixels | 1920(H) × 1080(V) |
| Video Frame Rate | 1080P@30fps / 1080P@25fps |
| Min. Illumination | 0.1 Lux / F1.6(Wide)~F2.8(Tele), 0 Lux (IR LED ON) |
| S/N Ratio | More than 48dB (AGC OFF) |
| Shutter Speed | 1 ~ 1/30000 |
| Lens | motorized f2.8 ~ f8.0mm / F1.6 ~ F2.8 (auto focus) |
| Lens Angle |
Wide: 90° (Horizontal) / 48° (Vertical) / 110° (Diagonal) |
| IR LED | 4 units |
| IR Effective Distance | Up to 60 meters |
| IR Shift | YES |
| Day & Night Mode | YES |
| Smart Light Control | YES |
| IRIS Mode | YES |
| White Balance | AWB |
| AGC | YES |
| Sharpness | YES |
| Flickerless | YES |
| BLC | YES |
| WDR | YES |
| External alarm I/O | Digital in * 1 / Digital out * 1 / 12V DC |
| IR Brightness Adjustment | YES |
| IP Rating | IP66 |
| Operating Temperature | -25℃ ~ 50℃ |
| Operating Humidity | 90% or less relative humidity |
| Power Source (±10%) | DC12V / 1A |
| Current Consumption (±10%) | 200mA (IR LED OFF) / 750mA (IR LED ON) |
| Net Weight | 2.4Kg |
